Coiling Machine MTP / CL-2
(1 STATION)

Home     Coiling Machine MTP / CL-2 (1 STATION)
coiling-machine

Technical Specification

MODEL MTP / CL-2
ROPE RANGE 2mm to 6mm
HEAD SPEED 400 RPM (Max.)
COIL SIZE MAX. 4 Kgs.
MOTOR POWER 1 HP, A.C. Motor
TRAVERSE SYSTEM Auto adjustable
DIMENSION (LxWxH) 2'9" x 2'6" x 4'8"
WEIGHT 250 Kgs.

Key Features :

Digital length counter meter.

Easy to operate.

Mechanical brake system at Pay of bobbin.

Optional Features :

A.C. frequency drive

Pneumatic head opening system
