| MODEL | MTP/E-20 |
|---|---|
| ROPE RANGE | 20mm to 54mm |
| STRAND FLYER RPM | Max. 250 |
| ROPE FLYER RPM | Max. 125 |
| TWIST RANGE | 5 to 15 TPM |
| TWIST PER MINUTE | Twice The Flyer Speed |
| ROPE LAY | Z |
| TWIST IN STRAND | Adjustable |
| PAY OFF PACKAGE SIZE | 250 mm Dia. × 300 mm Tra. |
| TAKE UP CAPACITY | 350 Kgs. |
Anti twisting unit.
Feeding capstan mechanism
User friendly touch screen display with PLC control.
All parameters will be shown on display.
RPM/TPM & twist factor adjustment by display.
Weight & Meter set point.
Direct Coiling Head
Denier & twisting calculator in display.
Door location warning.
Machine lubrication warning.
A.C. drive fault alarm indication.
100 program memory storage facility.
Daily, weekly & monthly report system. (Direct save in excel format)
Electrical Take up system
Ele. Wire hoist for removal of final package.
Wi-Fi connectivity system for computer.
Rope Lay S & Z.
| AVAILABLE MODELS | MTP/E-20-3150 | MTP/E-20-4200 |
|---|---|---|
| Motor Capacity | 40 KW | 40 KW |
| Number of Strand | 3 Ply | 4 Ply |
| Number of pay off package | 50 × 3 = 150 | 50 × 4 = 200 |
| Dimension (L × W × H) | 52'7" × 7'5" × 7'5" | 52'7" × 7'5" × 7'5" |
| ROPE SIZE | PROD. (KG/HR.) | TPM | RPM (MAX) | GRM/MTR |
|---|---|---|---|---|
| 20mm | 201.87 kg | 13.51 | 125 | 181.82 |
| 22mm | 268.51 kg | 12.29 | 125 | 220.00 |
| 24mm | 344.50 kg | 11.26 | 125 | 261.82 |
| 26mm | 390.00 kg | 10.40 | 110 | 307.27 |
| 28mm | 443.14 kg | 9.65 | 100 | 356.36 |
| 30mm | 544.85 kg | 9.01 | 100 | 409.09 |
| 32mm | 660.98 kg | 8.45 | 100 | 465.45 |
| 34mm | 598.61 kg | 7.90 | 75 | 525.45 |
| 36mm | 655.52 kg | 7.50 | 60 | 589.09 |
| 38mm | 655.60 kg | 7.10 | 60 | 656.36 |
| 40mm | 641.71 kg | 6.80 | 50 | 727.27 |
| 42mm | 751.70 kg | 6.40 | 50 | 801.82 |
| 44mm | 868.57 kg | 6.10 | 50 | 880.00 |
| 46mm | 983.12 kg | 5.87 | 50 | 961.82 |
| 48mm | 1122.07 kg | 5.60 | 50 | 1047.27 |
| 50mm | 1262.62 kg | 5.40 | 50 | 1136.36 |
| 52mm | 1418.18 kg | 5.20 | 50 | 1229.09 |
| 54mm | 1590.54 kg | 5.00 | 50 | 1325.45 |
