| MODEL | MTP/OP-12 |
|---|---|
| DENIER RANGE | 5000 TO 30000 DENIER |
| FLYER SPEED | 2800 RPM MAX |
| TWIST PER MINUT | 5600 TWIST MAX. |
| TWIST DIRECTION | S and Z |
| YARN FLOW | Outside |
| PAY OFF PACKAGE SIZE | DIA.400 MM X TRA. 300 MM (MAX.) |
| PAY OFF PACK_CAPACITY | 25 KGS (APPROX) |
| PACKAGE IN EACH STRAND | 1 |
| TPM RANGE | 20 TO 150 TPM |
| FINAL PACKAGE SIZE (ANY ONE) | 100 X 100 MM 150 X 150 MM 200 X 200 MM 250 X 250 MM |
| SPINDLE | CORELESS PNEUMATIC SPINDLE |
| NO OF LINE | 4 |
| POWER | 17 KW |
User friendly touch screen display
Tpm & Rpm Adjustment By Touch Screen Display
Winding tension adjustment by touch screen display
Pitch adjustment system
Auto stop at yarn breakage
Power transmission by timing belts
Ac frequency drives for all motors
Precision cross winding for final package
Electrically winding tension adjustment
Pneumatic spindle for removal of final package.
Wi-Fi connectivity system for computer.
With tube Spindle
| DENIER | PROD. (KG/HR.) | RPM (MAX) | TPM |
|---|---|---|---|
| 5,000 | 24.89 kg | 2800 | 50 |
| 10,000 | 49.78 kg | 2800 | 40 |
| 16,000 | 71.20 kg | 2500 | 40 |
| 20,000 | 88.80 kg | 2500 | 35 |
| 25,000 | 97.50 kg | 2500 | 35 |
