MODEL | MTP / CW-500 |
---|---|
PACKAGE SIZE | 500mm Tra. X 500mm dia. X 100 mm ID on tube. |
DENIER RANGE | 10,000 to 1,50,000 |
MOTOR | 3.7 KW with A.C. frequency drive. |
WINDING SPEED | 200 MPM. |
WINDING TYPE | Cheese winding with pitch adjustment. |
SPEED CONTROL | Electronic. |
TRANSMISSION | Timing belt. |
DIMENSION (LxWxH) | 2'11" x 4'11" x 4'11" |
WEIGHT | 500 kgs. |
Electric torque control.
Precision cross winding.
Online with extruder.
Easy to operate.
A.C. frequency drive.
