| AVAILABLE MODEL | MTP/STR-4-232 | MTP/STR-6-248 | MTP/STR-10-280 |
|---|---|---|---|
| Diameter Range | 4mm to 16mm | 6mm to 20mm | 10mm to 30mm |
| Pay of packages | 16 x 2 = 32 | 24 x 2 = 48 | 40 x 2 = 80 |
| Pay of package size | 250mm Dia. X 300 mm Traverse | 250mm Dia. X 300mm Traverse | 250mm Dia. X 300mm Traverse |
| TPM Range | 6 to 25 TPM | 6 to 25 TPM | 5 to 25 TPM |
| Twist per Minute | Twice the flyer speed | Twice the flyer Speed | Twice the flyer Speed |
| Rope Lay | S & Z | S & Z | S & Z |
| Flyer RPM | 500 RPM (Max.) | 450 RPM (Max.) | 300 RPM (Max.) |
| Take Up | Two Take Up Winder Head 480mm Dia. X 900mm Traverse (With Two Traverse Unit) | Two Take Up Winder head 560mm Dia. X 900mm Traverse (With Two Traverse Unit) | Two Take Up Winder head 600mm Dia. X 1000mm Traverse (With Two Traverse Unit) |
| Motor Power | 11 KW | 11 KW | 17.5 KW |
| Dimension (L x W x H) | 19' x 4'4" x 6'6" | 24' x 4'4" x 6'6" | 30' x 4'4" x 6'6" |
| Weight (Approx.) | 3800 Kgs. | 4900 Kgs. | 5800 Kgs. |
User Friendly touch screen display with PLC Control.
All parameters will be shown on display.
TPM & RPM adjustment by display.
Weight & Meter set point.
Denier & Twisting calculator in display.
Door location warning.
A.C. drive fault alarm indication.
100 program memory storage facility.
Daily, Weekly & Monthly report system. (Direct save in excel format).
Wi-fi connectivity system for computer.
